Siemens SIROTEC User Manual

Motor-side power components
10.1 Motor reactors
Booksize Power Units
566 Manual, (GH2), 07/2016, 6SL3097-4AC00-0BP8
Figure 10-2 Mounting hole
Table 10- 1 Dimensions of motor reactors, all dimensions in mm and (inches)
6SE7021-0ES87-1FE0
6SE7022-6ES87-1FE0
6SE7024-7ES87-1FE0
6SE7027-2ES87-1FE0
Fig. III
Fig. III
Fig. II
Fig. I
B
178 (7.00)
219 (8.62)
197 (7.75)
267 (10.51)
H
153 (6.02)
180 (7.08)
220 (8.66)
221 (8.70)
T
88 (3.46)
119 (4.68)
104 (4.09)
107 (4.21)
a
-
-
69 (2.71)
77 (3.03)
h
146 (5.74)
181 (7.12)
103 (4.05)
206 (8.11)
n
1
68 (2.67)
89 (3.50)
70 (2.75)
77 (3.03)
n
2
166 (6.53)
201 (7.91)
176 (6.92)
249 (9.80)
d
M5
M6
M6
M6
Lengths n1 and n2 correspond to the distances between holes
Table 10- 2 Dimensions of motor reactors, all dimensions in mm and (inches)
6SE7031-5ES87-1FE0
6SE7031-8ES87-1FE0
6SE7032-6ES87-1FE0
Fig. II
Fig. II
Fig. II
B
197 (7.75)
281 (11.06)
281 (11.06)
H
220 (8.66)
250 (9.84)
250 (9.84)
T 128 (5.03) 146 (5.74) 146 (5.74)
a
81 (3.18)
98 (3.85)
111 (4.37)
h 100 (3.93) 119 (4.68) 121 (4.76)
n
1
94 (3.70)
101 (3.97)
101 (3.97)
n
2
176 (6.92)
200 (7.87)
200 (7.87)
d
M6
M8
M8
Lengths n1 and n2 correspond to the distances between holes
