SDS1000CML+/SDS1000DL+ User Manual 109
■ Ready Data Success! : Read setup data or waveform data from the internal of
the oscilloscope or USB flash successful.
■ Please set Back USB to printer! : Press the “S/div” knob will appear this
information on the screen when the “Print Key” option is set to “Print Picture”
and the “Back USB” option is set to “USBTMC”.
■ USB Flash Drive isn’t connected! : When the “Save To” option is set to “File”
or the “Print Key” option is set to “Save Picture” in “Save/Recall” menu , Press
the “Save” option button or the “S/div” knob before inverting the USB Flash
Drive to the USB Host port will appear this information on the screen.
■ Record Wave Success! ：This message will appear when you finish recording
waveforms.
