SDS1000CML+/SDS1000DL+ User Manual 61
Manual Mode
Table 2-32 Manual cursor function menu:
Option
Setting
Instruction
Cursor Mode
Manual In this menu, set the manual cursor measure.
Type
Voltage
Time
Use cursor to measure voltage parameters.
Use cursor to measure time parameters.
Source
CH1
CH2
MATH
REFA
REFB
Select input signal channel.
Cur A
Select this option，use “Universal” knob to
adjust cursor A.
Cur B
Select this option，use “Universal” knob to
adjust cursor B.
In this mode, the screen displays two horizontal parallel cursors or vertical parallel
cursors to measure voltage or time. You can move the cursor by turning the
“Universal” knob. Before using cursors, you should make sure that you have set
the signal source as the channel for measuring.
■ Voltage Cursor: Voltage cursors appear as horizontal lines on the display and
measure the vertical parameters.
■ Time Cursor: Time cursors appear as vertical lines on the display and measure
the horizontal parameters.
■ Cursor Moving: Use the “universal” knob to move cursor1 and cursor2 .They
could be moved when the corresponding cursor option are selected, and cursor
value will display on the bottom left and top left of the screen when you move the
cursor.
To do manual cursor measurements, follow these steps:
1. Press CURSOR button to enter the cursor function menu.
2. Press the “Cursor Mode” option button to select “Manual”.
3. Press the “Type” option button to select “Voltage” or “Time”.
4. Press the “Source” option button to select “CH1”, “CH2”, “MATH”,
“REFA” ,“REFB” according to input signal channel.
5. Select “Cur A”, turn the “Universal” knob to adjust Cursor A.
6. Select “Cur B”, turn the “Universal” knob to adjust Cursor B.
