62 SDS1000CML+/SDS1000DL+ User Manual
7. The measurement values are displayed on the top of the left corner:
If the measurement type is set to “Voltage”, the values are:
The value of Cur A: CurA
The value of Cur B: Cur B
The voltage increment between Cursor A and Cursor B: △V
If the measurement type is set to “Time”, the values are:
The value of Cur A: CurA
The value of Cur B: Cur B
The time increment between Cursor A and Cursor B: △T
The reciprocal of time increment between Cursor A and Cursor B:
1/△T
Picture 2.11-2
