SIGLENT SDS1000CML+ - Appendix A: Default Setup

114 SDS1000CML+/SDS1000DL+ User Manual
Appendix A: Default Setup
Menu or system
options 、 knobs or
buttons
Default setup
CH1,CH2
Coupling DC
BW limit Off
Volts/div Coarse
Probe 1X
Invert Off
Filter Off
Volts/div 1.00V
MATH
Operation CH1+CH2
CH1 Invert Off
CH2 Invert Off
FFT operation:
Source CH1
Window Hanning
FFT Zoom 1X
Scale dBVrms
Display Split
HORIZONTAL
Window Main
Position 0.00μs
Sec/div 500μs
Window Zone 50.0μs
Trigger knob level
CURSOR
Type Off
Source CH1
Horizontal (voltage) +/-3.2divs
Vertical (time) +/-5divs
ACQUIRE
three mode options Sampling
Averages 16
Sampling mode Real Time
DISPLAY
Type Vectors
Persist off
Gird
Intensity 60%
Brightness 40%
Format YT
