SDS1000CML+/SDS1000DL+ Quick Start 9
The Front Panel
No. Description No. Description
1 Power On/Off 10 Trigger Control Area
2 Menus On/Off 11 Probe Compensation
3 Universal Knob 12 Horizontal Control Area
4 Function Menus 13 EXT TRIG Terminal
5 Default Setup 14 Vertical Control Area
6 Help 15 Channel Input Terminal
7 Single 16 Menu Select keys
8 Run/Stop 17 Print Key
9 Auto 18 USB Host Interface
