SIGLENT
SDS1000CML+/SDS1000DL+ User Manual 47
Operate Instruction:
Observe two irrelative channel signals, follow these steps：
1. Input two irrelative signals to channel 1and channel 2.
2. Press the AUTO button.
3. Press the TRIG MENU button to enter “trigger menu”.
4. Press the “Type” option button to select “Alternative”.
5. Press the “Channels” option button to select “CH1-CH2”
6. Press the “Source” option button to select “CH1”.
7. Press the CH1 button and turn the “S/div” knob to optimize waveform
display.
8. Press “Mode” option button to select “Edge”, “Pulse”, “Slope” or “Video”.
9. Set the trigger according to trigger edge.
10. Press the “Source” option button to select “CH2”.
11. Press the CH2 button and turn the “S/div” knob to optimize waveform
display.
12. Repeat steps 8 and 9.
2.8.3 Coupling
Use the “Coupling” to make sure the signal that passes the trigger circuit. It is
useful for us to gather a steady wave form.
If you use the trigger coupling, you should press the “TRIGGER” button and then
select “edge”, “Pulse”, “Video” or “Slope” trigger. Then select the “coupling” option
in “Set up menu”.
2.8.4 Position
The horizontal position control establishes the time between the trigger position
and the screen center. You can adjust the horizontal “POSITION” knob control to
view waveform data before the trigger, after the trigger, or some of each. When
you change the horizontal position of a waveform, you are changing the time
between the trigger and the center of the display actually. (This appears to move
the waveform to the right or left on the display.)
