SDS1000CML+/SDS1000DL+ Quick Start 23
Troubleshooting
The general failures and consequential solutions are listed below.
When you find them, please deal with them in the following
corresponding ways. If the problem proves to be unsolvable
yourself, please contact with SIGLENT as soon as possible.
1. The screen remains dark after power on:
(1) Check if the power is correctly connected.
(2) Check whether the fuse is burned out. If the fuse needs to be
changed, please contact with SIGLENT as soon as possible
and return the instrument to the factory to have it repaired by
qualified personnel authorized by SIGLENT.
(3) Restart the instrument after completing inspections above.
(4) If it still does not work normally, please contact SIGLENT.
2. After the signal is sampled, there is no corresponding
waveform displaying:
(1) Check if the probe is correctly connected to the signal
connecting cord.
(2) Check if the signal connecting cord is correctly connected to
BNC connector.
(3) Check if the probe is correctly connected to the item under
test.
(4) Check if there are signal generated from the item under test
(you can connect the probe compensation signal to the
problematic channel to determine the reason to the problem )
(5) Resample the signal.
