SIGLENT
108 SDS1000CML+/SDS1000DL+ User Manual
Chapter 3 Prompting Messages and
Troubleshooting
3.1 Prompting Messages:
■ Trig level at limit! : Mention you that the trigger Level is at a limit when you turn
the Trig level knob.
■ Horizon position at limit! : Mention you that the horizontal position is at a limit
when you turn the horizon position knob.
■ Volts/Div at limit! : Mention you that the vertical voltage have already touched
the Min 2MV/div or the Max 10V/div.
■ Volts position at limit! : The system would display this information when the
vertical position is at a limit.
■ Sec/Div at limit! : Prompts that the Volts/Div is at full range while turning the
vertical scale knob.
■ Holdoff time at limit! : Turn the “Universal” knob when holdoff time has been to
max or min value, now the system will clew this information.
■ Functions isn’t useable! : Under several special modes, the some functions
could not be running.
■ No signal! : The system would clew this information when the signal could not
match the auto set condition. (Using in the auto set)
■ Adjust at limit! : You could adjust the pulse width by the universal knob till the
pulse width has reached min20.0ns or max 10.0s.
■ Location Empty! : If you have no stored waveforms or setups on some location,
the screen will display this information when you press the “Recall” button on
this location.
■ USB Flash Drive Plug In! : This information will appear when you invert the
USB Flash Drive to the USB Host port.
■ USB Flash Drive Pull Out! : This information will appear when you pull out the
USB Flash Drive.
■ Store Data Success! : Save setup data, waveform data or picture data to the
internal of the oscilloscope or USB flash successful.
