SIGLENT
4 SDS1000CML+/SDS1000DL+ Quick Start
Connect to AC Power Supply
The oscilloscope accept 100～240V, 50/60/440Hz AC power supply.
Please use the power cord provided as accessories to connect the
instrument to the power source as shown in the figure below.
Note: In want of replacing the fuse, please return the instrument to
the factory that produced it to have it repaired by qualified
service personnel authorized by SIGLENT.
Power socket
