SDS1000CML+/SDS1000DL+ Quick Start 19
User Interface
1. Product logo
SIGLENT is the registered trademark of our company.
2. Working state
Available working states include Ready, Auto, Trig’d, Scan and
Stop.
3. USB Host connection identifier
When the USB Host is connected, the identifier is shown.
4. Waveform memory
Display the position of the current waveform in the memory of
the oscilloscope.
5. Trigger position
Display the trigger position of the waveform in the memory and
on the screen.
6. LAN Port connection identifier
: indicates the LAN port is connected successfully
: indicates the LAN port is disconnected
