SDS1000CML+/SDS1000DL+ Quick Start 15
RUN/STOP
: Press the button to set the state of the instrument to
“RUN” or “STOP”.
When in “RUN”, the indicator light displays yellow;
When in “STOP”, it displays red.
SINGLE
: Press the button to turn the trigger mode to “Single”.
AUTO
: Press the button to enable the waveform auto setting
function. The oscilloscope will automatically adjust the horizontal
time base, vertical scale and trigger mode according to the input
signal to make the waveform displays in a perfect state.
