SIGLENT
SDS1000CML+/SDS1000DL+ User Manual 33
The feature is very useful because you can see the events that led up the trigger
point everything to the right of the trigger point is called posttrigger information the
amount of delay range (pre-trigger and posttrigger information) available is
dependent on the sweep speed selected.
2.8.1 Signal Source
You can use the Trigger Source options to select the signal that the oscilloscope
uses as a trigger. The source can be any signal connected to a channel BNC, to
the EXT TRIG BNC or the AC power line (available only with Edge triggers).
