SIGLENT
SDS1000CML+/SDS1000DL+ User Manual 111
automatically.
6. After the Acquisition is set to Averages or Display Persistence time is set
too long, the waveform refreshes slowly.
It is normal in these settings
7. The signal is displayed as ladder like waveform
(1)This phenomenon is normal. The time base maybe is too slow .you should turn
the horizontal scale knob to increase horizontal resolution to improve the
display.
(2) Maybe the display Type is set to “Vectors”, You could set it to Dots mode to
improve the display.
