64 SDS1000CML+/SDS1000DL+ User Manual
B→V: The Vertical position of Cursor B (Voltage cursor centered
around channel ground level).
△T: Horizontal space between Cursor A and Cursor B (Time value
between two cursors).
1/△T: The reciprocal of horizontal space between cursor A and cursor
B.
△V: Vertical space between Cursor A and Cursor B (Voltage value
between two cursors).
Picture 2.11-3
