Simrad E50 Series User Manual

You can switch on and off all layers except User chart by right-clicking the Layers shortcut
button.
If any other layer than User chart is turned on, the light indicator in the Layers shortcut
button turns yellow.
You turn off all layers except User chart by left-clicking the Layers shortcut button.
Radar overlay
If a Simrad ARGUS radar is connected to the system, you can display radar overlay on the
chart.
Ú
Note: The Radar overlay has to be turned ON to see the radar image as an overlay on the
chart.
Object information
Information about an object is available in the Object information dialog.
The dialog is displayed by moving the cursor to the object and clicking the right cursor key.
The dialog shows a list of information for the selected object/area, and cursor position when
the right cursor key was pressed.
The number of objects in the Object information dialog depend on available information for
the selected area.
The user interface | E50xx ECDIS Operator Manual
15
