Simrad NSS evo3S Installation Manual

Compass safe distance
The unit outputs electromagnetic interference that can cause inaccurate readings on a
nearby compass. To prevent compass inaccuracy the unit must be mounted far enough
away so the interference does not affect compass readings. For minimum compass safe
distance, refer to "Technical specifications" on page 43.
GPS
It is important to test the GPS performance before the location of the unit is decided.
Construction material (steel, aluminum, or carbon) and heavy structure might affect GPS
performance. Avoid a mounting location where metal obstacles block the view of the sky.
A well placed external GPS module can be added to overcome poor performance.
A
B
C
A Optimal location (above deck)
B Less effective location
C Not recommended location
Ú
Note: Consider the lateral swinging if mounting the GPS sensor high above the sea level.
Roll and pitch might give false positions and affect the true directional movement.
Touchscreen
Touchscreen performance can be affected by the location of the unit. Avoid locations where
the screen is exposed to:
• Direct sunlight.
• Prolonged rainfall or floating water.
12
Installation | NSS evo3S Installation Manual

Simrad NSS evo3S Specifications

General

Connectivity	Wi-Fi, Bluetooth, NMEA 2000, Ethernet
Internal Memory	16 GB
External Memory	microSD card slot
Waterproof Rating	IPX6
Resolution	1280 x 720
Sonar	DownScan, SideScan
GPS	Built-in GPS/GLONASS
Processor	iMX8
Operating Voltage	10-32 V DC
Ethernet Ports	2
Radar Compatibility	Halo
Operating Temperature	-15°C to +55°C
Storage Temperature	-20°C to +60°C
Dimensions	Varies by model
Weight	Varies by model
Display Size	9, 12, or 16 inches
