Simrad NSS evo3S Installation Manual

The shadow cursor on a multiple panel page
When using the cursor on a sonar (sonar, DownScan, or SideScan) image on a multiple panel
page, the cursor is shadowed on the other sonar (sonar, DownScan, and SideScan), chart and
radar panels.
Customizing favorite pages
Adding new favorite pages
Ú
Note: The unit display size determines the number of favorite pages allowed and the
number of application panels that can be included on a favorite page.
Edit favorite pages
Select the edit button in the favorite panel and then:
• Select the X icon on a favorite button to remove the page
• Select the tool icon on a favorite button to display the page editor dialog
Customizing the instrument bar
Ú
Note: You must activate the instrument bar in the application to access the instrument
bar menu.
Turning the instrument bar ON or OFF
By default, the Instrument bar is shown on the panel.
You can turn the instrument bar ON/OFF from the System Controls dialog.
Select a predefined instrument bar
Use the menu to select a predefined activity based instrument bar.
Changing data
You can change data from the menu.
Customizing your system | NSS evo3S Operator Manual
21

Simrad NSS evo3S Specifications

General

Connectivity	Wi-Fi, Bluetooth, NMEA 2000, Ethernet
Internal Memory	16 GB
External Memory	microSD card slot
Waterproof Rating	IPX6
Resolution	1280 x 720
Sonar	DownScan, SideScan
GPS	Built-in GPS/GLONASS
Processor	iMX8
Operating Voltage	10-32 V DC
Ethernet Ports	2
Radar Compatibility	Halo
Operating Temperature	-15°C to +55°C
Storage Temperature	-20°C to +60°C
Dimensions	Varies by model
Weight	Varies by model
Display Size	9, 12, or 16 inches
