Battery and AC source connections
Color Indicates
Blue Current flow
Grey No current flow
Emergency power transfer
If your engine battery is low and you want to transfer power from the aux battery to the
engine battery, select this option.
Warning: Using a battery at a very low charge level can damage the
battery.
Naviop
If this device is on the same NMEA 2000 network as a Naviop Loop system, this device can be
used to operate the Naviop Loop system.
For details, refer to the documentation following the Naviop system.
Integration of 3 party devices| NSS evo3S Operator Manual
153

Simrad NSS evo3S Specifications

General

Connectivity	Wi-Fi, Bluetooth, NMEA 2000, Ethernet
Internal Memory	16 GB
External Memory	microSD card slot
Waterproof Rating	IPX6
Resolution	1280 x 720
Sonar	DownScan, SideScan
GPS	Built-in GPS/GLONASS
Processor	iMX8
Operating Voltage	10-32 V DC
Ethernet Ports	2
Radar Compatibility	Halo
Operating Temperature	-15°C to +55°C
Storage Temperature	-20°C to +60°C
Dimensions	Varies by model
Weight	Varies by model
Display Size	9, 12, or 16 inches
