Simrad NSS evo3S Installation Manual

The autopilot controller for outboard motors
A Control bar
B Autopilot controller, disengaged
C Autopilot controller, engaged
D Mode indication
E Mode buttons
F Turns button
G Mode dependent buttons
H Standby button
When the autopilot controller is the active panel, it is outlined with a border.
Engaging and disengaging the autopilot
To engage the autopilot:
• Select the engage button to activate last active mode
• Select the mode button to display the list of available modes, then select the preferred
mode
The autopilot will engage in the selected mode, and the autopilot controller will change to
show active mode options.
To disengage the autopilot:
• Select the standby button
When the autopilot is in standby, the boat must be steered manually.
Autopilot indication
The status bar shows autopilot information as long as an autopilot computer is connected.
Outboard autopilot| NSS evo3S Operator Manual
113

Simrad NSS evo3S Specifications

General

Connectivity	Wi-Fi, Bluetooth, NMEA 2000, Ethernet
Internal Memory	16 GB
External Memory	microSD card slot
Waterproof Rating	IPX6
Resolution	1280 x 720
Sonar	DownScan, SideScan
GPS	Built-in GPS/GLONASS
Processor	iMX8
Operating Voltage	10-32 V DC
Ethernet Ports	2
Radar Compatibility	Halo
Operating Temperature	-15°C to +55°C
Storage Temperature	-20°C to +60°C
Dimensions	Varies by model
Weight	Varies by model
Display Size	9, 12, or 16 inches
