Simrad NSS evo3S Installation Manual

Contents
7 Introduction
7
Parts included
8 Front controls
9 Card reader
10 Connectors
11 Installation
11 General mounting guidelines
13 U-bracket mounting
14 Panel mounting
14 Bezel fitment and removal
15 Wiring
15 Connectors
15 Wiring guidelines
15 Power
18 NMEA 2000
19 Video IN and NMEA 0183
21 Ethernet
22 Sonar CH1 - blue connector
22 Sonar CH2 - black connector
23 HDMI out
23 USB port
25 System setup
25 Turning the system on and off
25 First time startup
25 System setup sequence
25 The settings dialog
25 System settings
27 Activating/deactivating features and applications
27 Alarms
28 Radar installation
30 Echosounder settings
33 Autopilot settings
35 Fuel settings
36 Wireless settings
37 Network settings
40 3rd party support
40 CZone
41 Naviop
41 Mercury
41 Suzuki Marine
41 Yamaha
41 Evinrude
41 Power-Pole
41 FLIR camera setup
43 Appendix
43 Technical specifications
45 Dimensional drawings
46 Supported data
6
Contents | NSS evo3S Installation Manual

Simrad NSS evo3S Specifications

General

Connectivity	Wi-Fi, Bluetooth, NMEA 2000, Ethernet
Internal Memory	16 GB
External Memory	microSD card slot
Waterproof Rating	IPX6
Resolution	1280 x 720
Sonar	DownScan, SideScan
GPS	Built-in GPS/GLONASS
Processor	iMX8
Operating Voltage	10-32 V DC
Ethernet Ports	2
Radar Compatibility	Halo
Operating Temperature	-15°C to +55°C
Storage Temperature	-20°C to +60°C
Dimensions	Varies by model
Weight	Varies by model
Display Size	9, 12, or 16 inches
