Trolling motor speed control
In Heading lock mode, Nav. mode and in Turn pattern steering the autopilot system can
control the trolling motor speed.
The set target speed is displayed in the autopilot controller.
There are two ways to control the target speed of the trolling motor:
• Propeller rate, set as a percentage of power (A)
• Cruise control speed (B)
Switch between the speed options by selecting the speed icon.
The speed is increased/decreased in preset steps by selecting the plus and minus buttons.
The speed can also be set manually by selecting the speed field (C).
Recording and saving a track
A track can be saved as a route from the autopilot controller. If track recording is disabled, the
function can be enabled from the autopilot controller.
For more information, refer to "Waypoints, routes, and tracks" on page 40.
Autopilot settings
The options in the Autopilot settings dialog can vary.
Chart compass
Select to display a compass symbol around your boat on the chart panel. The compass
symbol is off when the cursor is active on the panel.
Select active autopilot
Selects if the autopilot controls the trolling motor or the outboard motor(s).
Auto hide autopilot bar
Controls whether the autopilot information bar is shown when the autopilot is in standby.
Arrival mode
The autopilot switches from navigation mode to the selected arrival mode when the vessel
reaches the destination point.
Standby
Disengages the autopilot. The trolling motor is controlled by hand-held remote or by foot
pedal.
Heading lock
Locks and maintains the last vessel heading.
Anchor
Anchors the vessel at the destination point.
Anchor point setup
The trolling motor can store a number of anchor points, labelled with MTG prefix. Anchor
points in the trolling motor are displayed in the Anchor point dialog.
These MTG anchor points can be saved as a waypoint in the MFD system. The position of an
MTG anchor point can be redefined to be identical to an existing waypoint, or to the current
vessel position.
110
Trolling motor autopilot| NSS evo3S Operator Manual
