Simrad NSS evo3S Installation Manual

Turn variables
All turn patters have settings that you can adjust before you start a turn, or at any time when
the boat is in a turn.
U-turn
Changes the current set heading by 180°.
Turn variable:
• Turn radius
C-turn
Steers the vessel in a circle.
Turn variable:
• Turn radius
• Degrees to turn
Spiral
Makes the vessel turn in a spiral with a decreasing or increasing radius.
Turn variables:
• Initial radius
• Radius change per loop
• Number of loops
Zigzag-turn
Steers the vessel in a zigzag pattern.
Turn variables:
• Course change per leg
• Leg distance
• Number of legs
Square
Steers the vessel in a square pattern, doing 90° course changes.
Turn variable:
• Leg distance
• Number of legs
S-turn
Makes the vessel yaw around the main heading.
Turn variables:
• Turn radius
• Course change
• Number of legs
Trolling motor autopilot| NSS evo3S Operator Manual
109

Simrad NSS evo3S Specifications

General

Connectivity	Wi-Fi, Bluetooth, NMEA 2000, Ethernet
Internal Memory	16 GB
External Memory	microSD card slot
Waterproof Rating	IPX6
Resolution	1280 x 720
Sonar	DownScan, SideScan
GPS	Built-in GPS/GLONASS
Processor	iMX8
Operating Voltage	10-32 V DC
Ethernet Ports	2
Radar Compatibility	Halo
Operating Temperature	-15°C to +55°C
Storage Temperature	-20°C to +60°C
Dimensions	Varies by model
Weight	Varies by model
Display Size	9, 12, or 16 inches
