Instruments
About Instrument panels
The panels consist of multiple gauges that can be arranged on dashboards. The panels can
be created with analog, digital, and bar gauges. Pre-defined dashboards and templates are
included.
Example:
Creating a dashboard
Use the new menu option to create your own dashboard.
Starting from blank
Select to create your own dashboard from scratch.
Use menu options to name the dashboard and manage gauges on the dashboard.
Copying an existing layout
Select to copy an existing layout that you have made.
Use menu options to name the dashboard and manage gauges on the dashboard.
Using a built-in template
Select a pre-defined template to create a dashboard. The template dashboards reflect your
vessel configuration.
Use menu options to name the dashboard and manage gauges on the dashboard.
19
Instruments| NSS evo3S Operator Manual
119

Simrad NSS evo3S Specifications

General

Connectivity	Wi-Fi, Bluetooth, NMEA 2000, Ethernet
Internal Memory	16 GB
External Memory	microSD card slot
Waterproof Rating	IPX6
Resolution	1280 x 720
Sonar	DownScan, SideScan
GPS	Built-in GPS/GLONASS
Processor	iMX8
Operating Voltage	10-32 V DC
Ethernet Ports	2
Radar Compatibility	Halo
Operating Temperature	-15°C to +55°C
Storage Temperature	-20°C to +60°C
Dimensions	Varies by model
Weight	Varies by model
Display Size	9, 12, or 16 inches
