Simrad NSS evo3S Installation Manual

Customizing the dashboard
You can use edit menu options to:
• change the data for each of the gauges in any dashboard
• set limits for analog gauges
• change the dashboard layout
Ú
Note: You cannot change the layout of pre-defined dashboards or dashboards you have
created using built-in templates.
Adding gauges
Select a gauge in the menu and then position it on the dashboard.
Key operation
Use arrow keys to select the item you want to add, and press the enter key.
Choosing gauge data
Select the gauge in the dashboard and then the info menu option to choose the data to be
shown on the gauge.
Selecting a dashboard
You switch between the dashboards by:
• swiping left or right on the panel
• selecting the dashboard from the menu
120
Instruments| NSS evo3S Operator Manual

Simrad NSS evo3S Specifications

General

Connectivity	Wi-Fi, Bluetooth, NMEA 2000, Ethernet
Internal Memory	16 GB
External Memory	microSD card slot
Waterproof Rating	IPX6
Resolution	1280 x 720
Sonar	DownScan, SideScan
GPS	Built-in GPS/GLONASS
Processor	iMX8
Operating Voltage	10-32 V DC
Ethernet Ports	2
Radar Compatibility	Halo
Operating Temperature	-15°C to +55°C
Storage Temperature	-20°C to +60°C
Dimensions	Varies by model
Weight	Varies by model
Display Size	9, 12, or 16 inches
