Simrad NSS evo3S Installation Manual

System settings
Language
Controls the language used on this unit.
Boat settings
Used to specify the physical attributes of the boat.
Text size
Used for setting the text size in menus and dialogs.
Key beeps
Controls the loudness of the beep sound that occurs when physical interaction is made with
the unit.
Time
Configure time settings to suit vessel location, along with time and date formats.
Satellites
The Satellites option displays a graphical view and numeric values for available satellites.
Ú
Note: The content in the Satellites dialogs varies with connected antenna.
From within this dialog you can select and configure the active GPS sensor.
PIN code
Sets a PIN code to prevent unauthorized access to your system's settings.
Note: Record the PIN code and store it in a safe place.
When you establish password protection, the PIN code must be entered when any of the
following are selected. After the correct PIN code is entered, all of them can be accessed
without re-entering the PIN code.
• Settings, activated from the home page or system controls dialog
• Alarms, activated from the toolbar
• Storage, activated from the toolbar
• Store, activated from the toolbar
140
Tools and settings| NSS evo3S Operator Manual

Simrad NSS evo3S Specifications

General

Connectivity	Wi-Fi, Bluetooth, NMEA 2000, Ethernet
Internal Memory	16 GB
External Memory	microSD card slot
Waterproof Rating	IPX6
Resolution	1280 x 720
Sonar	DownScan, SideScan
GPS	Built-in GPS/GLONASS
Processor	iMX8
Operating Voltage	10-32 V DC
Ethernet Ports	2
Radar Compatibility	Halo
Operating Temperature	-15°C to +55°C
Storage Temperature	-20°C to +60°C
Dimensions	Varies by model
Weight	Varies by model
Display Size	9, 12, or 16 inches
