Simrad NSS evo3S Installation Manual

Icon Definition
An external keyboard is connected to the unit.
An external mouse is connected to the unit.
A mobile (cell) phone is connected to the unit via Bluetooth.
The system is simulating. Turn ON/OFF the simulator from the simulator
settings dialog.
Radar is paused. If you want the radar to transmit, select the transmit
option in the Radar page menu.
Radar is transmitting. If you want to pause the radar, select the pause
option in the Radar page menu.
A compatible remote controller is connected to the unit.
The system is synchronizing data during startup.
File transfer problem, caused by an interruption in the internet
communication.
Trip recording. For more information, open the TripIntel tool option.
Uploading files, e.g.: service report, C-MAP genesis, route files to
PredictWind, etc.
Discover other marine GPS navigation on our website.

Simrad NSS evo3S Specifications

General

Connectivity	Wi-Fi, Bluetooth, NMEA 2000, Ethernet
Internal Memory	16 GB
External Memory	microSD card slot
Waterproof Rating	IPX6
Resolution	1280 x 720
Sonar	DownScan, SideScan
GPS	Built-in GPS/GLONASS
Processor	iMX8
Operating Voltage	10-32 V DC
Ethernet Ports	2
Radar Compatibility	Halo
Operating Temperature	-15°C to +55°C
Storage Temperature	-20°C to +60°C
Dimensions	Varies by model
Weight	Varies by model
Display Size	9, 12, or 16 inches
