Simrad NSS evo3S Installation Manual

• Charge a connected device. For maximum output power refer to the "Technical specifications"
on page 43.
• Connect a storage device.
• Connect a card reader.
Ú
Note: If you want to read chart cards using a USB card reader connected to the USB port,
an MI10 USB card reader is required.
The USB devices should be standard PC compatible hardware.
Ú
Note: USB cable length should not exceed 5 m when using regular cables. Lengths over
5 m may be possible with the use of an active USB cable.
USB connector details
Unit socket (female)
The unit is equipped with standard USB type-A connector(s).
24
Wiring | NSS evo3S Installation Manual

Simrad NSS evo3S Specifications

General

Connectivity	Wi-Fi, Bluetooth, NMEA 2000, Ethernet
Internal Memory	16 GB
External Memory	microSD card slot
Waterproof Rating	IPX6
Resolution	1280 x 720
Sonar	DownScan, SideScan
GPS	Built-in GPS/GLONASS
Processor	iMX8
Operating Voltage	10-32 V DC
Ethernet Ports	2
Radar Compatibility	Halo
Operating Temperature	-15°C to +55°C
Storage Temperature	-20°C to +60°C
Dimensions	Varies by model
Weight	Varies by model
Display Size	9, 12, or 16 inches
