Video output
9" unit Not applicable
12" and 16" units 1 port (HDMI 1.4 sink and HDCP)
Data card reader 2 slots (microSD, max 32 GB, FAT32)
Wireless 802.11b/g/n
Bluetooth Bluetooth 4.0 with support for Bluetooth
Classic
USB
9" and 12" units Not applicable
16" unit 1 port (USB A)
Output: 5 V DC, 1.5 A
Physical
Dimensions (W x H x D) Refer to "Dimensional drawings" on page 45
Weight (display only)
9" unit 1.4 kg (3.11 lbs.)
12" unit 3.1 kg (6.83 lbs.)
16" unit 4.7 kg (10.25 lbs.)
Compass Safe Distance - Metric, imperial 50 cm (1.7 ft)
Mounting type Bracket (Supplied) or panel mount
44
Appendix | NSS evo3S Installation Manual
