REPAIR PROCEDURES
TB24 Plus&26J Plus Maintenance Manual 6-17 © Jun 2022
Figure 6-26
Table 6-9
1.Oscillate counterbalance valve 8. Slewing buffer valve 15. Telescope counterbalance valve
2.Drive control valve 9. Cycloid motor 16. Lift counterbalance valve
3. Oscillate multi-way valve 10. Power unit 17. Level counterbalance valve
4. Hydraulic tank 11.Hydraulic rotary coupler 18. Platform duplex valve
5. Brake/2–speed control valve 12. High-pressure filter 19. Jib counterbalance valve
6. Oscillate control valve 13. Open type variable
displacement pump
7. Boom function manifold 14. Closed type variable
displacement pump
