© Jun 2022 2-10 TB24 Plus&26J Plus Maintenance Manual
SPECIFICATIONS
Component Metric (kg) Imperial (lb)
Engine installation
450 992
Note: The component weight may vary with different configurations selected.
HYDRAULIC SYSTEM
SPECIFICATIONS
Table 2-10
ITEM SPECIFICATION
Hydraulic Oil
Normal temperature region
(0℃~40℃ [32℉~104℉])
L-HM46
Low temperature region
(-25℃~25℃ [-13℉~77℉])
L-HV32
High temperature region (＞40℃ [104℉])
L-HM68
Extremely low temperature region
(＜-30℃ [-22℉])
Special program to be determined
Hydraulic Pump
Closed-circuit variable displacement pump
Displacement
45.9cc/r
Max drive pressure 28 MPa (4061 Psi)
Open-circuit variable displacement pump
Displacement
35cc/r
Max operating pressure 22 MPa (3190 Psi)
Drive motor
Type Plunger motor
Displacement
45 cc/r
Function Manifold
Boom function valve pressure 22 MPa (3190 Psi)
Compensator oil pressure 2.1 MPa (305 Psi)
Brake engage pressure 3.5 MPa (508 Psi)
Return Filter
Return filter bypass pressure 0.4 MPa (58 Psi)
High-pressure Filter
High-pressure filter bypass pressure 0.7 MPa (102 Psi)
