© Jun 2022 5-32 TB24 Plus&26J Plus Maintenance Manual
MAINTENANCE PROCEDURES
Figure 5-42 Deutz TD2011L04i engine oil
drain valve
Figure 5-43 Cummins QSF2.8t3TC72
engine oil drain valve
Figure 5-44 WEICHAI WP3.2 engine oil
drain valve
Figure 5-45 YUCHAI YCF3050 engine oil
drain valve
BURN HAZARD
Do not come in contact with the hot
engine oil when draining to avoid
burns.
NOTICE
The waste engine oil should be collected in a
suitable vessel for disposal or recycling. The
waste engine oil should be treated in compliance
with the environment laws or regulations.
7. Close the drain valve.
8. Add new engine oil. For the recommended viscosity
grade of the engine oil, please reference A-8
Inspect Engine Oil Level, page 5-8.
C-4 Replace Engine Oil Filter
NOTICE
Replace the engine oil filter each time the engine oil
is replaced.
1. Open the right turntable cover and locate the
engine oil filter. Remove the filter.
