SPECIFICATIONS
TB24 Plus&26J Plus Maintenance Manual 2-7 © Jun 2022
ENGINE SPECIFICATIONS
Table 2-3 Cummins QFS2.8t3TC72
Type Water-cooled
Number of
Cylinders
4
Bore
94mm (3.7 in)
Stroke
100mm (3.9 in)
Total
Displacement
2.8L
0.62 gal (UK)
0.74 gal (US)
Compression
Ratio
16.7:1
Firing Order
1-2-4-3
Output 54kw@2200rpm
Torque 270Nm (199 ft-lb)@1800rpm
Cooling
System
Capacity
3.5L
0.77 gal (UK)
0.92 gal (US)
Engine Oil
Capacity
8L
1.76 gal (UK)
2.11 gal (US)
Low RPM 1500rpm
High RPM 2200rpm
Table 2-4 Deutz D 2.9L4
Type
Water-cooled
Number of
Cylinders
4
Bore
92mm (3.6 in)
Stroke
110mm (4.3 in)
Total
Displacement
2.9L
0.64 gal (UK)
0.77 gal (US)
Compression
Ratio
17：1
Firing Order
1-2-4-3
Output 36.4kw@2600rpm
Torque 147Nm (108 ft-lb)@1600rpm
Cooling
System
Capacity
3.3L
0.73 gal (UK)
0.87 gal (US)
Engine Oil
Capacity
8.9L
1.96 gal (UK)
2.35 gal (US)
Low RPM 1500rpm
High RPM 2200rpm
Table 2-5 Deutz TD 2011 L04i
Type
Water-cooled
Number of
Cylinders
4
Bore
96mm (3.78 in)
Stroke
125mm (4.9 in)
Total
Displacement
3.68L
0.81 gal (UK)
0.97 gal (US)
Compression
Ratio
17：1
Firing Order
1-3-4-2
Output 55.4kw@2400rpm
Torque 240Nm (177 ft-lb)@1800rpm
Cooling
System
Capacity
3.3L
0.73 gal (UK)
0.87 gal (US)
Engine Oil
Capacity
8.9L
1.96 gal (UK)
2.35 gal (US)
Low RPM 1500rpm
High RPM 2200rpm
Table 2-6 WEICHAI WP3.2
Type
In-line, water-cooled, 4–stroke
Number of
Cylinders
4
Bore
98mm(3.86 in)
Stroke
105mm(4.13 in)
Total
Displacement
3.17L
0.70 gal(UK)
0.84 gal(US)
