Sinoboom TB24 Plus - Hydraulic System; Layout of Hydraulic Elements

© Jun 2022 6-16 TB24 Plus&26J Plus Maintenance Manual
REPAIR PROCEDURES
UNSAFE OPERATION HAZARD
• The output voltage of the machine
can be as high as 208/120V (North
America)/230V (Australia), and
electric shock can cause serious
injury or death. The maintenance
and operation personnel shall
comply with national or local
electrical safety regulations and
precautions to avoid possible
electric shock hazard.
UNSAFE OPERATION HAZARD
• Debugging must be performed by
the after-sales personnel of
Sinoboom. Do not debug the
machine without permission.
HYDRAULIC SYSTEM
Layout of Hydraulic Elements
Figure 6-25
1
2
3
4
7
8
10
5
12
13
11
14
6
9
