SPECIFICATIONS
TB24 Plus&26J Plus Maintenance Manual 2-9 © Jun 2022
Drive-stowed：With the machine on level surface,
switch to engine high idle and drive high speed, fully
stroke the drive control handle to drive forward and
reverse for 30m respectively. Test twice.
Drive-working：With the machine on level surface,
switch to engine high idle, fully stroke the drive control
handle to drive forward and reverse for 30m
respectively. Test twice.
MAJOR COMPONENT
WEIGHTS
UNSAFE OPERATION HAZARD
• Do not move heavy
components without
mechanical assistance.
• Do not place heavy
components upon instable
surfaces.
Table 2-9
Component Metric (kg) Imperial (lb)
Chassis assembly
2212 4877
Turntable assembly
7592 16737
Boom assembly
3470 7650
Base boom 891 1964
1st telescopic boom
468 1032
2nd telescopic boom
308 679
Jib boom assembly (TB26J Plus
only)
188 414
Platform 187
412
Counterweight
4898 10798
Slewing mechanism
367 809
Main boom telescopic cylinder
316 697
Main boom level cylinder, upper
39 86
Main boom level cylinder, lower
37 82
Main boom lift cylinder
373 822
Jib boom cylinder (TB26J Plus only)
34 75
Reducer and motor 130 287
Wheel assembly
299 659
Engine-Cummins QSF2.8t3TC72
214 472
Engine-Deutz TD2.9L4
269 593
Engine-Deutz TD2011L04i
266 586
Engine-WEICHAI WP3.2
270 595
Engine-Yuchai YCF3050
280 617
