MAINTENANCE PROCEDURES
TB24 Plus&26J Plus Maintenance Manual 5-21 © Jun 2022
Figure 5-23 High pressure filter
2. Place a suitable vessel under the filter.
3. Remove the filter from the mounting bracket.
4. Replace the filter element as needed.
5. Clean up the hydraulic oil spills.
6. Start the machine from the ground controller.
7. Inspect the high-pressure filter and relevant
components for leakage.
B-8 Replace Air Filter Element of
Engine
NOTICE
Shut off the engine before inspection.
Inspecting the engine air filter is vital to proper engine
operation. Failure to perform this inspection procedure
will result in engine malfunction and component
damage.
1. Open the right side cover of turntable.
2. Locate the engine air filter, as shown in the figure
below:
Figure 5-24 Deutz TD2.9 L4 air filter
Figure 5-25 Deutz TD2011L04i air filter
