TB24 Plus&26J Plus Maintenance Manual 7-1 © Jun 2022
7 REXROTH CONTROL SYSTEM
All operations in this section must be performed by
qualified personnel who have been professionally
trained and authorized by Sinoboom, otherwise the
consequences will be at your own risk.
UNSAFE OPERATION HAZARD
• The machine has been
commissioned before delivery.
It’s forbidden to modify the
system settings and update the
program without authorization
from Sinoboom.
Due to different machine
configurations, certain
descriptions below may be
inapplicable to your machine. In
case of any operational questions
when operating the machine as
per the manual, please stop
operation and contact Sinoboom
after-sales personnel in time.
• Incorrect operation may result in
death, serious injury or machine
damage.
NOTICE
PCU, ECU, sensors, etc. are precisely adjusted and
protected before delivery. Therefore, personnel who
have not been professionally trained and authorized
by Sinoboom cannot disassemble their housings,
otherwise moisture and dust will enter the internal
mechanism and normal operation will not be
guaranteed.
This section is applicable to Rexroth system equipped
with Rising display.
DISPLAY INTERFACE
The system interface is described in the figure below:
Note: some interfaces can only be accessed with a
password (the password can only be provided to
personnel professionally trained and authorized by
Sinoboom).
