MAINTENANCE PROCEDURES
TB24 Plus&26J Plus Maintenance Manual 5-33 © Jun 2022
Figure 5-46 Deutz TD2.9 L4 engine oil
filter
Figure 5-47 Deutz TD2011L04i engine oil
filter
Figure 5-48 Cummins QSF2.8t3TC72
engine oil filter
Figure 5-49 WEICHAI WP3.2 engine oil
filter
Figure 5-50 YUCHAI YCF3050 engine oil
filter
2. Drain the engine oil into a container.
3. Remove and discard the seal ring of the engine oil
filter.
4. Thoroughly clean the residues on the seal surface
of the filter support.
5. Apply clean engine oil to the rubber washer of the
new engine filter.
6. Mount the new filter.
7. For the engine oil level inspection procedure,
please reference A-8 Inspect Engine Oil Level,
page 5-8.
8. Inspect the engine oil filter element to make sure no
leakage occurs.
