REXROTH CONTROL SYSTEM
TB24 Plus&26J Plus Maintenance Manual 7-19 © Jun 2022
Figure 7-41 FAULT INFO interface 2
3. For the detailed description of faults codes of the
lifting motor and travel motor controllers, please
refer to the Fault Code Description for Electric
Motor Controller in the Maintenance Manual (if the
machine is equipped with a motor controller).
4. Lithium battery BMS fault Info: Press
to enter
Lithium Battery BMS Fault Info interface to check
the detailed description of lithium battery BMS fault
codes. For the detailed fault description, please see
BMS Fault Code Description for Lithium Battery
section in the Maintenance Manual (if the machine
is equipped with any lithium battery).
5. Press
successively to return to the main
interface, and power off the machine as required.
