Service Manual INTEGO / INTEGO pro 6.2Patient chair
båÖäáëÜ
Measuring points
Key
Connector
SS_All Bypass safety switches so that drives can move even if safety switches/foot switch have/has
been triggered
HEATER_SENS Activate heater
OPL_PW_ON Activate LEDlight
Measuring point Function
CAN+ Terminating resistor measurement
CAN- Terminating resistor measurement
DE+ Terminating resistor measurement (S-COM+)
DE- Terminating resistor measurement (S-COM-)
ASE+ Terminating resistor measurement (RS-485+)
ASE- Terminating resistor measurement (RS-485-)
FS_Poti Resistance measurement
36 V Voltage measurement
GND Voltage measurement
Key Function
RESET DSA RESET button
Source Destination Location Function
X2 X2 -> Power supply unit Patient chair Supply voltage
X4 X4 -> Power supply unit Patient chair Temperature and voltage monitoring
X3 X3 -> NOP Compact water unit Mini LED
X3 -> NOP Comfort assistant element Mini LED
X5 X5 -> DSS Patient chair Central unit memory for treatment center
X6 Heater Water unit Spray water heater
X7 Lift drive Patient chair Lift drive control
X8 Pneumatic foot switch - Chair control
X9 Backrest drive Patient chair Backrest drive control
X10 X21 -> DWEm Compact water unit Power supply
X21 -> DWB Compact water unit Automatic separation,
dry suction, wet suction, place selector,
suction hose cleaning
X3 -> DWV Compact water unit Air Venturi
X21 -> DWE Comfort water unit Power supply
Pad Function
