6Overview of modules and boards Sirona Dental Systems GmbH
6.2Patient chair Service Manual INTEGO / INTEGO pro
Battery
X11 X11 -> DSU Water unit USB camera
X11 -> DSU Dentist element USB camera
X11 -> DSU Assistant element USB camera
X12 LEDlight - LEDlight control
X13 Safety switches 3 and 4 Patient chair Lifting frame safety switch
X14 Safety switch 2 Water unit Safety switch, cuspidor
X15 XSF 4-way foot switch - 4-way foot switch
X16 Safety switch 7 Patient chair Backrest safety switch
X17 REF_LIFT Patient chair Lifting drive reference switch
Safety switch 6 Patient chair Safety switch, footrest
X18 REF_BR Patient chair Backrest drive reference switch
Safety switches 5 and 5a Patient chair Backrest cover safety switch
X19 Safety switch 4 Patient chair Safety switch, assistant element
X22 MV34 Water unit Tumbler filler
MV35 Water unit Flushing
X23 MVP1 Water unit Blowing air
MVP2 Water unit Chip blower
MVP3 Water unit Spray
X24 X24 -> DHT Compact assistant element User interface
X24 -> DHT Comfort assistant element User interface
X30 X30 -> DAB CS dentist element CS dentist element control
X30 -> DAB TS dentist element TS dentist element control
X35 X2 -> CFS electronic foot switch - Chair control electronic foot switch
X303 X303 -> DSL On DSA LAN interface
Battery Function
1 Li battery 3V CR2032 for clock
Source Destination Location Function
