Sirona Dental Systems GmbH 6Overview of modules and boards
Service Manual INTEGO / INTEGO pro 6.3Dentist element
båÖäáëÜ
Measuring points
Connector
MV21.3 yellow Illuminated: Motor/High-speed handpiece active
2x flashes: Solenoid valve shorted or overloaded
3x flashes: Solenoid valve affected by ground fault or line disruption
MV22 Green Illuminated: Siroson active
2x flashes: Solenoid valve shorted or overloaded
3x flashes: Solenoid valve affected by ground fault or line disruption
MV24 yellow Illuminated: Sprayvit active
2x flashes: Solenoid valve shorted or overloaded
3x flashes: Solenoid valve affected by ground fault or line disruption
MV29 yellow Illuminated: Rinsing active
2x flashes: Solenoid valve shorted or overloaded
3x flashes: Solenoid valve affected by ground fault or line disruption
LB yellow Photoelectric barrier closed (instrument removed)
FS_ACTIVE yellow Foot switch activated
DAI_EN yellow DAI instrument light circuit enabled
Measuring points Function
CAN+ Terminating resistor measurement
CAN- Terminating resistor measurement
36 V Voltage measurement
GND Voltage measurement
Source Destination Location Function
X2 X1 DAT/DAK Dentist Element Power supply and communication
X5 X5 (RÖBI) X-ray image viewer X-ray viewer illumination
X6 X1 DAP/DAPm Dentist Element motor/Sirosonic TL instrument control
X5 DAI Turbine/Sprayvit light control
X19 MV21.1, MV21.2, MV21.3,
MV22, MV29
Water unit Solenoid valve control
X30 X30 DSA Patient chair Power supply and communication for foot
switch, CAN, S-COM
LED Color Function
