Measuring points
Connector
BOOT yellow Lights up after switching on and remains lit until completion of the boot
process
INSTR yellow Off: Instrument deposited
Flashing:
1x Sprayvit
2x Turbine 1
3x Turbine 2
4x Turbine 3
5x Motor 1
6x Motor 2
7x Scaler
8x Polylight
INST_ACTIVE yellow Motor/Sirosonic active (output stage)
LIGHT yellow Instrument light activated
FS_ACTIVE yellow Foot control signal active
Measuring points Function
CAN+ Terminating resistor measurement
CAN- Terminating resistor measurement
36V Voltage measurement
GND Voltage measurement
Source Destination Location Function
X1 X6 DAB TS dentist element Power supply, communication, CAN,
instrument light, foot control
X6 DAB CS dentist element Power supply, communication, CAN,
instrument light, foot control
X2 Sirosonic TL TS dentist element Instrument control
Sirosonic TL CS dentist element Instrument control
X3 Sirosonic TL TS dentist element Instrument light
Sirosonic TL CS dentist element Instrument light
X5 X2 DC_DC_Converter Patient chair Power supply
X7 X31 NAA TS dentist element APEX
X31 NAA CS dentist element APEX
X8 X8 DAR Dentist Element Instrument control
Motor 1 Dentist element flange Instrument light
X9 X9 DAR Dentist Element CAN, Mini LED, APEX, instrument control
LED Color Function
