64 57 316 D3543
D3543.076.01.04.02 06.2015
71
Sirona Dental Systems GmbH 6Overview of modules and boards
Service Manual INTEGO / INTEGO pro 6.3Dentist element
båÖäáëÜ
Function of the board
● Communication via CAN with the DAR
● Supply for instrument light (LED only)
● Control of motor BL ISO E
● Activation of scaler handpiece
● Via the DAR board: Mini LED power supply
X10 X10 DAR Dentist Element Instrument light
Motor 1 Dentist element flange Instrument control
Source Destination Location Function
