Sirona Intego - Page 78

64 57 316 D3543
78 D3543.076.01.04.02 06.2015
6Overview of modules and boards Sirona Dental Systems GmbH
6.4Water unit Service Manual INTEGO / INTEGO pro
Measuring points
Connector
MV33 yellow Illuminated: Activation of place selection valve active
2x flashes: Solenoid valve shorted or overloaded
3x flashes: Solenoid valve affected by ground fault or line disruption
MV37 yellow Illuminated: Drain flap active
2x flashes: Solenoid valve shorted or overloaded
3x flashes: Solenoid valve affected by ground fault or line disruption
MV52 yellow Illuminated: Flushing active
2x flashes: Solenoid valve shorted or overloaded
3x flashes: Solenoid valve affected by ground fault or line disruption
ASE_SUC yellow Illuminated: Suction hoses removal detection active
DS30 yellow Illuminated: Separation tank full
DN30/DS yellow Illuminated: Water monitor active (DN30)/
Level detection for cuspidor valve: reed switch DS actuated
S52 yellow Illuminated: Flushing active
OPL_PW Green Illuminated: Supply voltage LEDlight active
Measuring points Function
CAN+ Terminating resistor measurement
CAN- Terminating resistor measurement
36 V Voltage measurement
GND Voltage measurement
Source Destination Location Function
X1 Holder 2, holder 3, holder 4 Assistant element Removal detection
X2 Amalgam separator centrifugal
motor
Water unit Control of amalgam separator centrifugal
motor
X4 Amalgam separator Water unit Amalgam separator speed sensor
X7 S3 Water unit Amalgam separator safety switch
X8 X30 DSA Patient chair SCOM, CAN, foot switch, power supply
X12 MV33 (suction valve) Water unit Suction valve control
X13 Reed switch DS (cuspidor valve
in Dürr wet suction system)
Water unit Level sensor for cuspidor valve in Dürr
wet suction system
DS30 (automatic separator) Water unit Level sensor for separation tank
X15 MV52/S52 Water unit Control of flushing for suction hose
cleaning
X18 MSBV - Dürr wet suction system Water unit Control of cuspidor valve
X21 X10 DSA Patient chair Power supply
LED Color Function
