64 57 316 D3543
D3543.076.01.04.02 06.2015
79
Sirona Dental Systems GmbH 6Overview of modules and boards
Service Manual INTEGO / INTEGO pro 6.4Water unit
båÖäáëÜ
Function of the board
● Recognition
– Of instrument removal in assistant element
● Control
– Of hydropneumatic pump
– Of automatic separation
– Of amalgam separator with water monitor
– Of cuspidor valve in Dürr wet suction system
– Of flushing for suction hose cleaning
– Of suction machine
● Communication with the other components of the dental treatment
center
X30 X30 DSA Patient chair SCOM, CAN, foot switch, power supply
X31 X30 DAB Dentist element SCOM, CAN, foot switch, power supply
X44 Suction pump Water unit Activation of suction pump
X45 OP lamp - Control of LEDview
Source Destination Location Function
