Sirona Dental Systems GmbH 6Overview of modules and boards
Service Manual INTEGO / INTEGO pro 6.4Water unit
båÖäáëÜ
MV3 yellow Illuminated: Dentosept solenoid valve active
2x flashes: Solenoid valve shorted or overloaded
3x flashes: Solenoid valve affected by ground fault or line disruption
MV33 yellow Illuminated: Activation of place selection valve active
2x flashes: Solenoid valve shorted or overloaded
3x flashes: Solenoid valve affected by ground fault or line disruption
MV37 yellow Illuminated: Drain flap active
2x flashes: Solenoid valve shorted or overloaded
3x flashes: Solenoid valve affected by ground fault or line disruption
MV40.1 yellow Illuminated: Hydropneumatic pump (MV40.1) active
2x flashes: Solenoid valve shorted or overloaded
3x flashes: Solenoid valve affected by ground fault or line disruption
MV40.2 yellow Illuminated: Hydropneumatic pump (MV40.2) active
2x flashes: Solenoid valve shorted or overloaded
3x flashes: Solenoid valve affected by ground fault or line disruption
MV52 yellow Illuminated: Flushing for suction hose cleaning active
2x flashes: Solenoid valve shorted or overloaded
3x flashes: Solenoid valve affected by ground fault or line disruption
MV51 yellow Illuminated: Chemical flushing for suction hose cleaning active
2x flashes: Solenoid valve shorted or overloaded
3x flashes: Solenoid valve affected by ground fault or line disruption
MSBV yellow Illuminated: Cuspidor valve active
2x flashes: Solenoid valve shorted or overloaded
3x flashes: Solenoid valve affected by ground fault or line disruption
MV1 yellow Illuminated: Water inlet solenoid valve active
2x flashes: Solenoid valve shorted or overloaded
3x flashes: Solenoid valve affected by ground fault or line disruption
MV38 yellow Illuminated: Solenoid valve for Sprayvit water valve active
2x flashes: Solenoid valve shorted or overloaded
3x flashes: Solenoid valve affected by ground fault or line disruption
DS31.1 yellow Illuminated: Mixing tank level switch active (DS31.1)
DS31.2 yellow Illuminated: Mixing tank level switch active (DS31.2)
DS32 yellow Illuminated: Disinfection tank level switch active (DS32)
ASE_SUC yellow Illuminated: Suction hoses removal detection active
ASE_SV yellow Illuminated: Sprayvit removed
DS30 yellow Illuminated: Separation tank full
LED Color Function
