Sirona Intego - Page 82

64 57 316 D3543
82 D3543.076.01.04.02 06.2015
6Overview of modules and boards Sirona Dental Systems GmbH
6.4Water unit Service Manual INTEGO / INTEGO pro
Push button
Measuring points
Connector
DN30/DS yellow Illuminated: Water monitor active (DN30)/
Level detection for cuspidor valve: reed switch DS actuated
DS51 yellow Illuminated: Chemical flushing for suction hose cleaning active
OFF: Chemical tank empty
S52 yellow Illuminated: Flushing for suction hose cleaning active
OPL_PW Green Illuminated: Supply voltage LEDlight active
CLEAN SW yellow Illuminated: "CLEAN_SWITCH" button active
Suction machine is started manually in order to empty the cuspidor valve
CUP FILL yellow Illuminated: Morita automatic tumbler filling active
Push button Function
S_DESINF Button for emptying disinfection tank
S_MB Button for emptying mixing tank
Measuring points Function
CAN+ Terminating resistor measurement
CAN- Terminating resistor measurement
36 V Voltage measurement
GND Voltage measurement
Source Destination Location Function
X1 Holder 2, holder 3, holder 4 Assistant element Removal detection
X2 Amalgam separator centrifugal
motor
Water unit Control of amalgam separator centrifugal
motor
X4 Amalgam separator Water unit Amalgam separator speed sensor
X7 S3 Water unit Amalgam separator safety switch
X8 X30 DSA Patient chair SCOM, CAN, foot switch, power supply
x11m CN1 and CN3 NWM (Morita) Water unit Automatic tumbler filling
X12 MV33 (suction valve) Water unit Suction valve control
X13 Reed switch DS (cuspidor valve
in Dürr wet suction system)
Water unit Level sensor for cuspidor valve in Dürr
wet suction system
DS30 (automatic separator) Water unit Level sensor for separation tank
X14 Taste Clean Switch (cuspidor
valve)
Water unit Taste Clean Switch Empty cuspidor valve
X15 MV52/S52) Water unit Control of flushing for suction hose
cleaning
LED Color Function
