Sirona Dental Systems GmbH 6Overview of modules and boards
Service Manual INTEGO / INTEGO pro 6.4Water unit
båÖäáëÜ
Function of the board
● Recognition
– Of instrument removal in assistant element
● Control
– Of chemical disinfection system
– Of hydropneumatic pump
– Of automatic separation
– Of amalgam separator with water monitor
– Of cuspidor valve in Dürr wet suction system
– Of flushing for suction hose cleaning
– Of suction machine
● Supply of Morita board (automatic tumbler filling)
● Communication with the other components of the dental treatment
center
X16 DS51/MV51 Water unit Control of chemical tank
X18 MSBV - Dürr wet suction system Water unit Control of cuspidor valve
X21 X10 DSA Patient chair Power supply
X25 MV40.1/MV40.2 Water unit Pump valve control
X26 MV3/DS32 Water unit Disinfection system valve control
X27 MV1/DS31.1/DS31.2/water inlet Water unit Disinfection system valve control, water
inlet
X30 X30 DSA Patient chair SCOM, CAN, foot switch, power supply
X31 X30 DAB Dentist Element SCOM, CAN, foot switch, power supply
X40 Holder 1/Sprayvit with LEDlight Assistant element Removal detection, Sprayvit with LEDlight
X41 MV38 Water unit Sprayvit solenoid valve
X44 Suction pump Water unit Activation of suction pump
X45 OP lamp - Control of LEDview
Source Destination Location Function
