74
4.1 Information on assembly
The assembly procedure for the product
is described in detail in the assembly
instructions (Chapter 4) associated with these
operating instructions.
4. Assembly
MKU gear pump unit, Fig. 1
2
3
4 1
5
6
7
8
9
10
EN
4. Assembly
5. Functional description
5.1 General
Gear pump units are reservoir units with
electrically driven gear pumps that contain
all hydraulic and electrical components
required for the operation of a piston
distributor system or an oil+air centralized
lubrication system. Thanks to their compact
construction, gear pump units can be used
to set up piston distributor systems to
lubricate small and mid-sized machines,
machine groups and systems very easily
and with low mounting effort.
